Produkto kodas: CP.EN.00000222.01

DJI Matrice 300 RTK

Kaina: 13000
Kaina išsimokėtinai: Lizingo skaičiuoklė Skaičiuoti kainą
  • Skrydžio laikas iki 55 min
  • 15 km 1080p vaizdo perdavimas
  • 6 Krypčių jutimas ir padėties nustatymas
  • Darbinė temperatūra nuo -20°C iki 50°C

Į kainą įskaičiuota:

  • DJI Matrice 300 RTK Dronas
  • Valdymo pultas
  • Baterijų komplektas
  • Baterijų įkrovimo stotis
Matyti daugiau
Grąžinimas
Nemokamas grąžinimas per 14 dienų. Daugiau informacijos
13000
  • DJI Matrice 300 RTK 1 13000
Viso: 13000
Dėti į krepšelį Pristatymas per 1-2 d.d.
Naujausias DJI dronas, pasirodęs 2020 metų pradžioje ir skirtas gelbėjimo operacijoms, paieškoms, skraidyti sudėtingose situacijose. Pasižymi nauju bei kompaktišku dizainu. DJI Matrice 300 RTK komplektacija
YouTube video
Category Item Specification
Aircraft Dimensions Unfolded, propellers excluded, 810×670×430 mm (L×W×H) Folded, propellers included, 430×420×430 mm (L×W×H)
Aircraft Diagonal Wheelbase 895 mm
Aircraft Weight (with single downward gimbal) Approx. 3.6 kg (without batteries) Approx. 6.3 kg (with two TB60 batteries)
Aircraft Max Payload 2.7 kg
Aircraft Max Takeoff Weight 9 kg
Aircraft Operating Frequency 2.4000-2.4835 GHz 5.725-5.850 GHz
Aircraft EIRP 2.4000-2.4835 GHz: 29.5 dBm (FCC); 18.5dBm (CE) 18.5 dBm (SRRC); 18.5dBm (MIC) 5.725-5.850 GHz: 28.5 dBm (FCC); 12.5dBm (CE) 28.5 dBm (SRRC)
Aircraft Hovering Accuracy (P-mode with GPS) Vertical: ±0.1 m (Vision System enabled) ±0.5 m (GPS enabled) ±0.1 m (RTK enabled) Horizontal: ±0.3 m (Vision System enabled) ±1.5 m (GPS enabled) ±0.1 m (RTK enabled)
Aircraft RTK Positioning Accuracy When RTK enabled and fixed: 1 cm+1 ppm (Horizontal) 1.5 cm + 1 ppm (Vertical)
Aircraft Max Angular Velocity Pitch: 300°/s, Yaw: 100°/s
Aircraft Max Pitch Angle 30° (P-mode, Forward Vision System enabled: 25°)
Aircraft Max Ascent Speed S mode: 6 m/s P mode:5 m/s
Aircraft Max Descent Speed (vertical) S mode: 5 m/s P mode:3 m/s
Aircraft Max Descent Speed (tilt) S Mode: 7 m/s
Aircraft Max Speed S mode: 23 m/s P mode:17 m/s
Aircraft Service Ceiling Above Sea Level 5000 m (with 2110 propellers, takeoff weight ≤ 7 kg) / 7000 m (with 2195 propellers, takeoff weight ≤ 7 kg)
Aircraft Max Wind Resistance 15 m/s
Aircraft Max Flight Time 55 min
Aircraft Supported DJI Gimbals Zenmuse XT2/XT S/Z30/H20/H20T
Aircraft Supported Gimbal Configurations Single Downward Gimbal, Dual Downward Gimbals, Single Upward Gimbal, Upward and Downward Gimbals, Triple Gimbals
Aircraft Ingress Protection Rating IP45
Aircraft GNSS GPS+GLONASS+BeiDou+Galileo
Aircraft Operating Temperature -20°C to 50°C (-4°F to 122° F)
Remote Controller Operating Frequency 2.4000-2.4835 GHz 5.725-5.850 GHz
Remote Controller Max Transmitting Distance(unobstructed, free of interference)) NCC/FCC: 15 km CE/MIC: 8 km SRRC: 8 km
Remote Controller EIRP 2.4000-2.4835 GHz: 29.5 dBm (FCC) 18.5dBm (CE) 18.5 dBm (SRRC); 18.5dBm (MIC) 5.725-5.850 GHz: 28.5 dBm (FCC); 12.5dBm (CE) 20.5 dBm (SRRC)
Remote Controller External battery Name: WB37 Intelligent Battery Capacity: 4920 mAh Voltage: 7.6V Type: LiPo Energy: 37.39Wh Charging time (using BS60 Intelligent Battery Station): 70 minutes (15°C to 45°C); 130 minutes (0°C to 15°C)
Remote Controller Built-in battery Type: 18650 lithium ion battery (5000 mAh @ 7.2 V) Charging: Use a USB charger with specification of 12V / 2A Rated power: 17 W Charging time: 2 hours and 15 minutes (Using a USB charger with specification of 12V / 2A)
Remote Controller Battery Life Built-in battery: Approx. 2.5h Built-in battery+External battery: Approx. 4.5h
Remote Controller USB Power Supply 5 V / 1.5 A
Remote Controller Operating Temperature -20°C to 40°C (-4 °F to 104 °F)
Vision System Obstacle Sensing Range Forward/Backward/Left/Right:0.7-40m Upward/Downward:0.6-30m
Vision System FOV Forward/Backward/Downward:65° (H), 50° (V) Left/Right/Upward:75°(H), 60°(V)
Vision System Operating Environment Surfaces with clear patterns and adequate lighting (> 15 lux)
Infrared ToF Sensing System Obstacle Sensing Range 0.1-8m
Infrared ToF Sensing System FOV 30° (±15°)
Infrared ToF Sensing System Operating Environment Large, diffuse and reflective obstacles (reflectivity >10%)
Top and bottom auxiliary light Effective lighting distance 5 m
FPV Camera Resolution 960p
FPV Camera FOV 145°
FPV Camera Frame rate 30 fps
Intelligent Flight Battery Name TB60
Intelligent Flight Battery Capacity 5935 mAh
Intelligent Flight Battery Voltage 52.8 V
Intelligent Flight Battery Battery Type LiPo 12S
Intelligent Flight Battery Energy 274 Wh
Intelligent Flight Battery Net Weight Approx. 1.35 kg
Intelligent Flight Battery Operating Temperature -4°F to 122°F (-20°C to 50°C)
Intelligent Flight Battery Ideal storage temperature 71.6°F to 86°F (22°C to 30°C)
Intelligent Flight Battery Charging Temperature -4°F to 104°F (-20°C to 40°C) (When the temperature is lower than 5°C, the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
Intelligent Flight Battery Charging time Using BS60 Intelligent Battery Station: 220V input: 60 minutes (fully charging two TB60 batteries), 30 minutes (charging two TB60 batteries from 20% to 90%) 110V input: 70 minutes (fully charging two TB60 batteries), 40 minutes (charging two TB60 batteries from 20% to 90%)
BS60 Intelligent Battery Station Dimensions 501*403*252mm
BS60 Intelligent Battery Station Net Weight 8.37kg
BS60 Intelligent Battery Station Maximum Capacity TB60 Intelligent Flight Battery × 8 WB37 Intelligent Battery × 4
BS60 Intelligent Battery Station Input 100-120 VAC,50-60 Hz / 220-240 VAC,50-60 Hz
BS60 Intelligent Battery Station Max. Input Power 1070W
BS60 Intelligent Battery Station Output Power 100-120V: 750W 220-240V:992W
BS60 Intelligent Battery Station Operating Temperature -4°F to 104°F (-20°C to 40°C)
